Description
- Rated output voltage 12 or 24V DC with the possibility of regulation
- Hight efficiency of up to 90%
- Low ripple & noise
- Wide voltage range input 100-240V AC
- Protection: Over load, Over voltage and Short circuit
- LED indication of output voltage
- Continuously adjustable output voltage to adapt tot the specific application, e.g. the need to compensate for the voltage drop caused by the lenght of the line.
Technical parameters
- Voltage range: AC 100 – 240 V (50 – 60 Hz)
- Burden with full load (max.):
- 16 W / 30 VA (PS1M-15/12V)
- 17,5 W / 32 VA (PS1M-15/24V)
- Electronic fuse against: short circuit, overload and overvoltage
- Protection degree: IP20
- Dimmension: 90 x 18 x 58 mm
- Weight: 78g
